SCHNEIDER POWER MODULE
SYPM4KI


Main Input Voltage
230 V
400 V 3 phase
Product or Component Type
Power module
Other Input Voltage
220 V
240 V
380 V
415 V
Main Output Voltage
230 V
Other Output Voltage
220 V
240 V
Kw Rating
2800 W
Rated power in VA
4000 VA
Output connector type
Hard Wire 3-wire (H N + E) 1
Number of rack unit
4U
Provided Equipment
Installation guide
Batteries & Runtime
Run Time
View Runtime Graph
Included Battery Modules
0
Battery Slots Empty
0
Additional information
Configurable for 220 : 230 or 240 nominal output voltage
Physical
Height
5.91 in (15 cm)
Width
9.84 in (25 cm)
Depth
22.24 in (56.5 cm)
Net Weight
33.07 lb(US) (15 kg)
mounting location
Front
Mounting preference
No preference
Mounting Mode
Not rack-mountable
USB compatible
No
Input
Input Frequency
45...65 Hz auto-sensing
Efficiency at full load
155...276 V 1:1
290...480 V 3:1
Input Power Factor at Full Load
0.98
Output
Max Configurable Power (Watts)
2800 W
Output Frequency (sync to mains)
50 Hz +/- 0.1 % for 50 Hz nominal not synced
60 Hz +/- 0.1 % for 60 Hz nominal not synced
Crest factor
Up to 5 : 1
Topology
Double Conversion Online
Wave type
Sine wave
Conformance
Product Certifications
C-tick
CE
GOST
VDE
Standards
EN 50091-1
EN 50091-2
EN 55022 Class A
EN 55024
EN 60950
IEC 60950
Environmental
Ambient Air Temperature for Operation
32…104 °F (0…40 °C)
Relative Humidity
0…95 %
Operating altitude
0...10000 ft
Ambient Air Temperature for Storage
5…113 °F (-15…45 °C)
Storage Relative Humidity
0…95 %
Storage altitude
0…15000 ft (0.0000000000…4572.0000000000 m)
Acoustic level
62 dBA
Ordering and shipping details
GTIN
731304218883
Country of origin
PH
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
17.28 in (43.9 cm)
Package 1 Width
13.0 in (33 cm)
Package 1 Length
22.2 in (56.5 cm)
Package 1 Weight
40.08 lb(US) (18.18 kg)
